Epoxy resin, mixed with pigment, may be used as a painting medium, by pouring layers on top of each other to form a complete picture. It is also used in jewelry, as a doming resin for decorations and labels, and in decoupage type applications for art, countertops, and tables.
It is two-part epoxy system with High Glossy , Transparent, low viscosity and UV stable liquid epoxy resin for casting, coatings, and adhesive applications. It is a range of high-performance user-friendly epoxy resins.
The two components ( Resin & hardener ) should be stored in separate at all times prior to use. Store in cool , Dry & Away from Sun Light.
Warm Temperature should be avoided in storage area , Warm temperature reduce the shelf life. The handling equipment & the storage area should be free from chemical residue , Foreign matters.
| Sr.No | DESCRIPTION | PARAMETERS | |
| RESIN | HARDENER | ||
| 1 | Physical State | Low Viscous Liquid | Low Viscous Liquid |
| 2 | Colour | Clear | Clear |
| 3 | Viscosity (mPas 25 ºC) | 1160 | 479 |
| 4 | Mixing Ratio | 100 | 60 |
| 5 | Gel Time @ 25 ºC (Min) | 5-10 min | |
| 6 | Set Time (Min) | 15-20 Min | |
| 7 | Drying Time (Min) | 30-40 Min | |
| CAST A and CAST B | |
| Viscosity Part A cps 25 °C | 900.00 cps |
| Viscosity Part B cps 25 °C | 10.00 cps |
| Appearance A/B | Clear Liquid/ Clear Liquid |
| Density Part A/Part B at 25 °C g/ml | 1.01/0.98 |
| Mixing Ratio A:B | 100:30 |
| Gel time in bulk at 25 °C | 60-90 min |
| A Epoxy Equivalent weight | 240 g/eq |
| B Active-H Equiv. Weight | 72 g/eq |
| Tacky free at 25 °C | 5-6hrs |
| Hardness in Shore D ASTM D 2240 | 5 |
| Minimum reaction temperature | +15 °C |
| Maximum temperature of use after hardening | 60 °C |
