Ultra High Gloss Clear Transparent Epoxy Resin

Epoxy resin, mixed with pigment, may be used as a painting medium, by pouring layers on top of each other to form a complete picture. It is also used in jewelry, as a doming resin for decorations and labels, and in decoupage type applications for art, countertops, and tables.

TECHNICAL SPECIFICATION

It is two-part epoxy system with High Glossy , Transparent, low viscosity and UV stable liquid epoxy resin for casting, coatings, and adhesive applications. It is a range of high-performance user-friendly epoxy resins.

FEATURES & BENEFITS:

  • 100% Clear & Transparent.
  • High Gloss Finishing Green
  • Non Yellowing
  • Can be Pigmented using suitable pigments
  • Very less shrinkage
  • Industry leading UV stability
  • Excellent moisture protection barrier, stable in acidic pH solutions
  • Excellent flow properties (low viscosity) with efficient substrate wetting
  • Unique mechanical properties

STORAGE & PRE –MIXING:

The two components ( Resin & hardener ) should be stored in separate at all times prior to use. Store in cool , Dry & Away from Sun Light.

Warm Temperature should be avoided in storage area , Warm temperature reduce the shelf life. The handling equipment & the storage area should be free from chemical residue , Foreign matters.

TECHNICAL GUIDELINES FOR USING:

  • Measure the Part A ( Resin ) and the Part B ( Hardener ) in two separate containers.
  • Transfer Part A into the suitable Glass Beak
  • Start gentle stirring
  • After stirring the part A, transfer Part B to it.
  • Continue the gentle stirring & Reaction to progress.
  • Take care not to get air trapped within mixture
  • The Mixed epoxy resin should be applied or poured within 5-10 min Time.
  • For design applications, Degassing may be required to remove the Air bubbles from the texture.
  • Upon curing remove the material from moulds.
  • SHELF LIFE:
  • Twelve (12) months from date of shipment when stored at 25ºC in the original sealed packages.

FIRST AID:

  • Eye Contact: Flush eyes with plenty of water. If irritation persists, seek medical attention.
  • Skin Contact: In case of skin contact, wash thoroughly with soap and water; remove contaminated clothing and launder before reuse; seek medical attention if rash develops.
  • Ingestion: Do not induce vomiting unless instructed by a physician. Contact physician immediately.

Ultra High Gloss Clear Transparent Epoxy Resin

ULTRA HIGH GLOSS & TRANSPARENT EPOXY RESIN - BUCR53

Sr.No DESCRIPTION PARAMETERS
RESIN HARDENER
1 Physical State Low Viscous Liquid Low Viscous Liquid
2 Colour Clear Clear
3 Viscosity (mPas 25 ºC) 1160 479
4 Mixing Ratio 100 60
5 Gel Time @ 25 ºC (Min) 5-10 min
6 Set Time (Min) 15-20 Min
7 Drying Time (Min) 30-40 Min

ULTRA HIGH GLOSS & TRANSPARENT EPOXY RESIN - BUCR2153

CAST A and CAST B
Viscosity Part A cps 25 °C 900.00 cps
Viscosity Part B cps 25 °C 10.00 cps
Appearance A/B Clear Liquid/ Clear Liquid
Density Part A/Part B at 25 °C g/ml 1.01/0.98
Mixing Ratio A:B 100:30
Gel time in bulk at 25 °C 60-90 min
A Epoxy Equivalent weight 240 g/eq
B Active-H Equiv. Weight 72 g/eq
Tacky free at 25 °C 5-6hrs
Hardness in Shore D ASTM D 2240 5
Minimum reaction temperature +15 °C
Maximum temperature of use after hardening 60 °C
